Drop Target Assemblies - confd
5-Bank Drop Target Assembly
C-13116
tern
Part Number
Description
Item Part Number
Description
1
C-13272
5-Bank Target Sub·Assy.
7
01·8413
Coil Mounting Bracket
a)
C·13158
Bracket & Stud Assy.
8
4008·01016·10
MS, 8·32 x 518 (3 used)
b)
03·8334·5
Target Strip
9
4408-01128·00
Nut, 8·32 KEPS (6 used)
c)
4004-01005·04
MS, 4-40 x 1/4 P (6 used)
10
03-8036
Plain Target (5 used)
2
A-11397
Stop Bracket Assembly
11
20-8712-25
"E" Ring, 1/4~ Shaft (10)
3
4408·01119-00
Nut, 8·32 ESN (4 used)
12
4700-00072-00
FW, 17/64 x
1/2
x 21 gao (15)
4
AE·24-900
Con Assembly
13
10-392
Extention Spring (5 used)
5
03·7066-4
Coil Tubing
14
10-364
Retractor Spring (5 used)
6
A·13159
Plunger/Reset Plate Assy.
15
23·6626
Rubber Grommet (4 used)
a)
01-9384
Reset Plate
16
C-13239
5·Bank Opto Board Assy.
b)
02-3972-1
Plunger
17
4700-00016-00
FW, 3116 x 7116 x 17
gao
(2)
c)
4410-01132-00
Nut, 10-32 ESN
18 20-8712-18
"E~ Ring, 3/16" Shaft (3)
5-10
