5~7a
Drop Target Assemblies· cont'd
1-Bank Drop Target Assembly
A-1S211
Item Part Number
Desaiption
hem Part Number
Desaiption
1 03·8033
Target, Flush
16 07-6688-17N
Rivet. 5132 x
118 (2)
2 A-15841
Bracket
&
Post Ass'y
17 10-433
Extension Spring
3
4408-0111'9.00
Nut 8-3,2 ESNA (4)
18 5070·09054-00
Diode 1N4001 1.0A
4 A-11397
Stop Bracket
Ass'y
19 5647·12693·31
Mini Micro Switch
5
AE·26-12oo
Coil Assembly
20 01-8600
Switch Insulator
6 01·8413
Coil Mounting Brkt.
21 4002·01105·10
MS 2·56 x 518 P·PH (2)
7 03·7066-4
Coil Tubing
22 01-8240
Nut Plate
12-56
a
A-113S8-2
PlungerlPlate Reset Ass'y
23 03-8630
Actuator Guide
9
4700-00072·00
FW.
17/64
x
112
x 21gao(4)
24 01·8647·R
Actuator
10 1()..392
Compression Spring
25 A-8936
Armature Sub-Assembly
11 20-8712·25
"e"
Ring,
1/4"
Shaft (2)
26 A-15209
Frame & ,Eyelet Assembly
12 01·10183
Switch Bracket
27 1()..363
Extension Spring
13 4006-01003·03
US 6132x
3116
P·PH (6)
28 SM1-26-600
Coil Asseni:Jly
14 03-8034
Single Stop TfI'get
29 4008-01 021·06
MS 8-32 x 318 P·PH
15 4010-01025-14
US 10-32 x
718
P·PH
30 4700.()(l089·QO FW 11.64x 7116 x 16
gao
31 4701-00003-00
lW,aSpli1
1••Bank Drop Target Assembly
A.•
16267
(Same as A·15211, except eliminate items 24 1hru 31)
A~15211
A·16267
ELECTRONICS GAMEB.INC.
