Page 393 - Williams RED Parts Catalog 16-9190-B

R.O. Wire Switch & Bracket Assemblies - cont'd
A-12687 Switch/Brkt Ass'y 2
a) 01-8719 Mounting Bracket
b) 4002-01005-08 MS 2-56x3/8 P-PH (2)
c) 4701-00024-00 LW #2 Split (2)
d) 5070-06258-00 Diode 1N4001 1.0A
e) 5647-12073-18 Mini-Micro Switch
(See p. 4-26)
5647-12693-19
A-12688 Switch/Brkt Ass'y 9
a) 01-8719 Mounting Bracket
b) 4002-01005-06 MS 2-56x3/8 P-PH (2)
c) 4701-00024-00 LW #2 Split (2)
d) 5070-06258-00 Diode 1N4001 1.0A
e) 5647-12073-19 Mini-Micro Switch
(See p. 4-26)
Game and Switch Part No.
THE MACHINE (50002)
5647-12693-04
Used On
Assembly Part No.
A-11619-'
(See p, 4-22a)
Description
Quantity
Per Game
1
5647-12693-25
A-14319"
·See p. 3-30
Switch/Brkt Ass'y
Loop Assembly
ELECTRONICS GAMEB.INC. 4-26a
