Rollover Wire Switch & Bracket Assemblies - cont'd
Game and Switch No.
Used On
Assembly Part No.
Description
Quantity
Per Game
WHIRLWIND (574)
5647-12073-19
(See
p.
4-23)
A-12688
(See
p.
4-26)
I
Switch & Brkt. Ass".
I
8
5647-12073-25
B-13349-
a) B-13223
b) 01-8240
c) 4002-01005-08
d) 4701-00024-00
e) 5070-06258-00
1) 5647-12073-25
Main Loop Assembly
Main Loop Sub-Assy.
Nut Plate #2-56
MS 2-56xl f2 P-PH (2)
LW #2 Split (2)
Diode 1N4001 1.0A
Mini-Micro Switch
B-13350·
a) 8-13221
b) 01-8240
c) 4002-01005-08
d) 4701-00024-00
e) 5070-06258-00
1) 5647-12073-25
·See p, 3-23
Side Loop Assembly
Side Loop Sub-Assy.
Nut Plate #2-56
MS
2-56x1/2
P-PH (2)
LW #2 Split (2)
Diode 1N4001 1.0A
Mini-Micro Switch
3-Switch & Brkt. Assy.
Mounting Bracket
MS
2-56x3/8
P-PH (6)
lW
#2 Split (6)
Diode 1N4001 1.0A (3)
Mini-Micro Switch
Mini-Micro Switch
Mini-Micro Switch
1
5647-12073-32
5647-12073-33
(See p. 4-23)
5647-12073-34
5647-12133-04
8-13289
a) 01-9465
b} 4002-01005-06
c) 4701-00024-00
d) 5070-06258-00
s) 5647-12073-32
1) 5647-12073-33
g) 5647-12073-34
(See p. 4-26)
Rear Ramp Assembly
0-13129
(See p. 3-24)
4-24
