Page 388 - Williams RED Parts Catalog 16-9190-B

4-22b
Rollover Wire Switch and Bracket Assemblies
Shooter lane Rollover Wire Switch & Bracket Assemblies
Diner Whirl Bleats Roller
Part Number Description 571 574 575 576
Game and Part Quantity
A-11619 R.O. Wire SwitchlBrkt. 1 1 1 1
a) 01-8240 Nut Plate
b) 01-8617 Mounting Bracket
c) 5070-09054-00 Diode 1N4004 t.OA
d) 5647-12693-04 Mini-Micro Switch
Mach Fun River Hurr Term2
Part Number Description 50002 50003 50007 50012 50013
Game and Part Quantity
A-11619 R.O. Wire Swi1chIBrkt. 2 1
A-11619-1 R.O. Wire SwitchIBrkt. 1 1
A-11619-2 R.O. Wire SwitchIBrkt. 1
b} 01-8617-1 Mounting Bracket
Note: All parts are identical except as indicated.
Drac Get Fish White
Part Number Description 50001 50004 50005 50018
Game and Part Ouantity
A-11619 RO. Wire SwitchlBracket 1 1
A-11619-1 A-11619
A-11619-2
~~e ELECTRONICSGAMEB.INC.
