Page 384 - Williams RED Parts Catalog 16-9190-B

Ball Gate Assemblies - contd
Ball Gate Assembly
Ball Gate Flap
Mounting Bracket
Ball Gate Wire
Hinge Pin
Quantity
Per Game FISH TALES (50005) Part Number Description
B-10732-L
a) 01-6935
b) 01-6938-1
c) 12-6657-L
d) 12-6882-1
Quantity
WHITE WATER (50018) Part Number Description Per Game
See drawing below A-16099 Dual BrkVSwitch Gate 1
Assembly
a) 01-11020 Dual Mtg. Bracket
b) 12-7043 Gate Wireform (2)
c) 01-8240 Nut Plate #2-56 (2)
d) 01-8600 Insulator (2)
e) 5070-09054-00 Dk>de 1N4001 (2)
f) 5647-12693-11 Mini-Micro Sw (2)
g) H-15994 Cable Assembly
