Page 382 - Williams RED Parts Catalog 16-9190-B

Ball Gate Assemones - conro
TERMINATOR 2 (50013) Part Number Description
Quantity
Per Game
Ball Gate Assembly
Mounting Bracket
Ball Gate Wire form
1 A-13S05-1
a) 01-9602
b) 12-6910
A-13627-2 Bali Gate/Switch Ass'y 1
a) 01-8240 Nut Plate
b) 01-8600 Insulator
c) 01-9654-2 Mounting Bracket
d) 12-6938 Ball Gate Wireform
e) 5070-09054-00 Diode 1N4004 1.0A
f) 5647-12693-11 Mini-Micro Switch
A-14492 Ball Gate/Switch Ass'y 1
a) 01-8240 Nut Plate
b) 01-8600 Insulator
c) 01-9654-3 Mounting Bracket
d) 12-6967 Ball Gate Wireform
e) 5070-09054-00 Diode 1N4004 1.OA
f) 5647-12693-11 Mini-Micro Switch
A-14536 Ball Gate Assembly 1
a) 01-10135 Return Spring
b) 01-10137 Mounting Bracket
c) 07-6688-1 Rivet
d) 12-6971 Ball Gate Wireform
A-14536-1
a} 01-10137
b} 12-6971
Ball Gate Assembly
Mounting Bracket
Ball Gate Wireform
1
4-20d ~~e ELECTRONICSGAMEB.INC.
