Page 379 - Williams RED Parts Catalog 16-9190-B

Ball Gate Assemblies- cont'd
Part Number
A·12511
A-14042
a) 01-8240
b) 01·9847
c) 12-6944
d) 5070-09054-00
e) 5647-12693-36
A-14281
a) 01-8240
b) 01·9970
c) 12·6958
d) 5070-09054-00
e) 5647-12693-36
A-14363
a) 01-6935
b) 01·9055·1
c) 12-6882-1
d) 12-6657-L
A-14372
a) 01-10023
b) 12-6962
A-14609
a) 01-10178
b) 12-6978
Description
Ball Gate Assembly
Ball Gate/Switch Ass'y
Nut Plate
Mounting Bracket
Actuator Wire
Diode 1N4004 1.OA
Mini-Micro Switch
Ball Gate/Switch Ass'y
Nut Plate
Mounting Bracket
Actuator Wire
Diode 1N4004 1.0A
Mini-Micro Switch
Ball Gate Assembly
Ball Gate Bracket
Mounting Bracket
Hinge Pin
Ball Gate Wireform
Ball Gate Assembly
Mounting Bracket
Ball Gate Wireform
1-Way Ball Gate Ass'y
Mounting Bracket
Bal/ Gate Wireform
U)f~e ELECTRONICS GAMEB.INC.
Quantity
Per Game
THE MACHINE (50002)
1 See Bad Cats (575), p. 4-19
1
4
1
1
1
