Page 328 - Williams RED Parts Catalog 16-9190-B

(574)
Wireform, Ball Gate & Spin Target Locations
Item Part No. Description
1 12-6842 Bottom Arch Fence
2 12-6466·10 Wireform, 1-112· (3 used)
3 A-8244-L One-Way Ball Gate - Left
4 A-12506 Ball Gate Assembly
5 A-13376 Ball Gate Assembly
6 8-13339 Spin Target Assembly
7 A-8244-R One-Way Ball Gate - Rgt.
8 0-13191 Wire Ramp Assembly
9 A-8645 Rollover Wire & Brkt Assy.
10 A-5844-44 Rollover Wire & Brld Assy.
11 A-5844-45 Rollover Wire & Brkt Assy.
12 12-6542 Trough Baffle Wire
4-2 nu-rr- ~e 7'~ ELECTRONICSGAMEB.INC.
