Screened Bottom Arch - cont'd
(With Related Hardware)
A-13204-GameM
Diner
Whirl
BICats
Roller
Part Number
Description
571
574 575
576
Game and Part Quantity
12-6842
Wire Fence
1
1
1
1
20-9041
Tinnerman Speednut
2
2
2
2
20-9045
Instruction Card Cover
2
2
2
2
20-9601·
#8-32 Nut Retainer
4
4
4
4
23-6313-1
Rubber Grommet
1
1
1
1
31-1008-Game
#
Screened Bottom Arch
1
1
1
1
4008-01017-10·
MS 8-32 x 5/8 P-RH-S
4
4
4
4
4700-00011-00·
FW
.172 x .437 x .059
4
4
4
4
Related hardware mounted on Playfield
01-5575
Mounting Bracket
2
2
2
2
01-8419
Hold-Down Bracket
2
2
2
2
"Used in conjunction with Wire Fence. See Section 4,
p.
4-15 for drawing.
31-1008-Game
tI
20-9041
3-34
filJ/_·II_·
1fD
7'~
