Page 215 - Williams RED Parts Catalog 16-9190-B

SEO Version

Ball Guide and Ramp Locations
(50013)
Item Part Number
Description
1 B-8239-2
Left Flipper Return Frame
2
A-14486
Ball Guide Assembly
3 A-14477
Ball Guide Assembly
4 A-14596
Ball Guide Assembly
5 01-6933
Ball Stop/Deflector (2 used)
6 01-10092
Ball Guide
7 01-10159
Ball Guide
8 A-14614
Ball Guide Assembly
9
A-14484
Ball Guide Assembly
10 A-14502
Ramp Assembly
11 A-14481
Ball Guide Assembly
12 01-10091
Ball Guide
13 A-14812
Right Plastic Ramp Ass'y
14 A-14610
Ball Guide Assembly
15 A-14488
Ball Guide Assembly
16 A-14482
Ball Guide Assembly
17 B-12695
Right Flipper Return Frame
Located Under Bottom Arch:
18 B-8623
Upper Trough Baffle
19 01-3569-1
Ball Trough Runway
20 C-8235
Lower Trough Baffle
21 31-1008-50013 Screened Bottom Arch
Not shown:
A-14961
Ball Guide, Skull Ass'y
(See p. 3-18r)
