Plumb Bob & Wire Assy.
A-8476
Used on all Pinball Games
+---~-----01-3444
Upper Tilt Brkt.
1+----~---12-6231
Plumb Bob Wire
01-3445
--- -H-
Lower Tilt Brkt.
.~---
4406-01120-00
Wing Nut (2 used)
20-6502-A
-~~~+-
Plumb Bob
5070-06258-00
Diode, 1N4001 1.0A
Tilt Switch
8-8306
(Located under Playfield)
Used on Bad Cats (575)
SW-1A-117-
Shake Switch
01-96
Switch Limit
-----01-3670-1
Switch Plate
~----
01-2642-14A
Mounting Bracket
2-10
