Flipper Button & Switch Assemblies - cont'd
Drac
Get
Fish
White
Part Number
Description
50001 50004 50005 50018
Game and Part Quantity
A-15878
Flipper Optc Ass'y, Double
2
2
2
a} A-15894
Optc Sw. PCB Assembly
b) 01-10939
OPIC
Interrupter
c) 06-86
Back Up Blade (2)
d) A-15893
Optc Mounting Bracket
e) 4006-01003-04 MS 6-32 x
1/4
popS (2)
f) 4406-0111
g-OO
Nut 6-32 ESN (2)
B-12273-4
Flipper Button Ass'y, Red
2
2
2
2
A-15058
6
Flipper, Single Switch Ass'y
1
A-15060·
Flipper, Double Switch
Ass'y
1
·See Section 6.
Interior of Cabinet
(Shown for reference)
----
PC Board
Elastic Stop Nuts
< ,~ . \)
<;
,.tI
--.."
~
.~
Mach inescrews~ :
I,
ELECTRONICS GAMEB.INC.
2-6aa
