Page 157 - Williams RED Parts Catalog 16-9190-B

Ripper Button & Switch Assemblies - cont'd
Mach Fun River Hurr Term 2
Pa.rt Number Description 50002 50003 50007 50012 SC013
Game and Part Quantity
8-12273-4 Flipper Button Ass'y
a) 03-8192-4 Nylon Button (Red) 2 2
b) 03-8193-4 Button Housing (Red) 2 2
8-12273-5 Flipper Button Ass'y
a) 03-8192-5 Nylon Button (White) 2
b) 03-8193-5" Button Housing (White) 2
B-12273-6 Flipper Button Ass'y
a) 03-8192-6 Nylon Button (Yellow) 2 2
b) 03-8193-6 Button Hsg. (Yellow) 2 2
A-999Q-2 Flipper Sw/cable Ass'y 2
1 SW-10A-53 w/5043-09072-DO Cap.
SW-10A-48 Flipper Switch 2 1 1 2
SW-101 OA-13 Flipper Switch 1 1
Flipper Switch
(See chart)
Note: All parts are the same as on p. 2-6 except where indicated.
U)f~e ELECTRONICS GAMEB.INC. 2-6a
