Page 114 - Williams RED Parts Catalog 16-9190-B

1-28f
CabinetlPlayfield
Mach Fun River Hurr Term2
Part Number Description 50002 50003 50007 50012 50013
H-10978-1 AC Line Filter Cable x x x
H-12192-50007 Cabinet Cable x
H-13544-50007 Playfield Switch Cbl x
H-13545-50007 Playfield Lamp Cable x
H-13546-50007 Playfield Solenoid Cbl x
H-13831-50003 Playfield Switch Cable x
H-13832-50003 Playfield Lamp Cable x
H-13833-50003 Playfield Solenoid Cbl x
H-13835-50003 Cabinet Cable x
H-13870 Black Jumper Cable x x
H-13937 Ramp Switch Cable x
H-13938 Main Ramp Cable x
H-14252-1 Motor Cable x
H-14252-2 Ramp Switch Cable x
H-14252-3 Rudy's Eyes Cable x
H-14252-4 Rudy's Kicker Cable x
H-14252-5 Opto Detector Cable x
H-14252-6 Opto Transmitter Cbl x
H-14252-7 Upper Ramp Cable x
H-14252-8 Lower Ramp Cable x
H-14252-9 Flasher Panel Cable x
H-14252-10 Mirror Cable x
H-14252-11 Wireform Switch Cbl x
H-14252-12 Single Lamp Cable x
H-14252-13 G. I. Lamp Cable x
H-14252-14 Opto Cable x
H-14425-1 Left Ramp Cab_Ie x ;
H-14425-2 Right Ramp Cable x
H-14425-3 Lower Head Cable x
o.Jf'~e ELECTRONICS GAMEB.INC.
