Page 96 - BallyMidway GREY Parts Catalog 16-9562-A

Printed Circuit lamp Board Assemblies - cont'd
Indy500 World hadw Corvet Addam Magic Who?
Part Number Description 50026 50031 50032 50036 50038 50039 50044
Game and Part Quantity
A-19982 18-Lamp PCB Ass'y 1
24-8768 #555 Light Bulb (18) (18)
24-8767 Twist Socket (12) (12)
24-8857 Horizontal Wedge Socket (6) (6)
A-19109 19-1amp PCB Ass'y 1
24-8768 #555 Light Bulb (19) (19)
24-8767 Twist Socket (19) (19)
A-20530 19-Lamp PCB Ass'y 1
24-8768 #555 Light Bulb (19) (19)
24-8767 Twist Socket (19) (19)
A-18068 21-Lamp PCB Ass'y 1
24-8768 #555 Light Bulb (21) (21 )
24-8767 Twist Socket (21) (21 )
Notes:
1. See pp. 1-1 thru 1-7 for Lamp Board Locations.
2. Matrix tables and schematics are available in the Operation Manuals listed on p. 7-1.
1-42d (j]af6; /MIDWAY
