Cable Connectors
Plugs and Jacks
Male
Female
Male
Female
(Examples)
Size: .093
Male
Female
Description
5791-10393-00
5792-10392-00
1 Pin Connector
@
[001
5791-12570-00
5792-12561-00
2 Pin Connector
5791-09580-00
5792-09454-00
2 Pin High Insulation
l(QJol
[0001
5791-09111-00
5792-09110-00
3 Pin Connector
5791-09400-00
5792-10910-00
4 Pin Connector
~oool
5791-09320-00
5792-09319-00
4 Pin High Insulation
5791-13202-00
5792-09108-00
6 Pin Connector
~
5791-09316-00
5792-10798-00
6 Pin High Insulation
0
000
5791-10916-00
5792-10917-00
9 Pin High Insulation
000000
000
000
5791-09572-00
5792-09109-00
12 Pin Connector
000000
000
5791-10353-00
5792-10354-00
15 Pin Connector
000
5791-12562-00
5792-12569-00
15 Pin High Insulation
000000000
1-32
