Page 591 - BallyMidway GREY Parts Catalog 16-9562-A

Small Steel Parts
Ball Shooter Gauges
Crea Judge TwiZ Pop
Part Number Description 20018 20020 50020 50022
Game and Part Quantity
31-1009-20018 Screened Shooter Gauge x
31-1743 Screened Shooter Gauge x
Note: Shooter Gauges for Judge Dredd and Popeye are part of the Bottom Arch Assembly,
Indy500 World Shadw Corvet Addam Magic Who?
Part Number Description 50026 50031 50032 50036 50038 50039 50044
Game and Part Quantity
31-1009-20017 Screened Shooter Gauge x
31-1998 Screened Shooter Gauge x
31-1009-50031 Screened Shooter Gauge x
31-1009-50039 Screened Shooter Gauge x
Note: Shooter Gauges for Indianapolis 500, Shadow, and Who?Dunnit are part of the Bottom Arch - see Section 3.
31-1009-20018
31-1009-50031
31-1009-50039
31-1998
31-1009-20017
31-1743
(j]ai!fLt /MIDWAY 7-21
