Page 543 - BallyMidway GREY Parts Catalog 16-9562-A

Stationary Target Assemblies - cont'd
Dual Target Assembly
A-20505-6
Description
2-Target Bracket
1" Dia. Plastic Target (2)
Edge Protector (2)
Switch Limit Stop (2)
Diode, 1N4004, 1.0A (2)
Cable Assembly
Part Number
01-14078
03-8093-6
23-6684-2
01-8657
5070-09054-00
H-19736
Item
1
2
3
4
5
6
Misc. Blade Parts:
Blade & Contact Ass'y (2)
1/6" Tight Spacer (4)
1/32" Spacer (2)
3/32" Loose Spacer (2)
Insulator (2)
Back Up Blade (4)
End Lug (4)
A-8378
01-916-S
01-916-T
01-916-H
06-73-2
06-20-20
06-1F-14
(jJafPLt /MIDWAY 6-6a
