5-102
Unique Assemblies - cont'd
THEATRE
of
MAGIC (50039)
Magic Trunk Assembly
A-19778
Item Part Number
Description
1 04·10001
2 01-13627
3 04-10003
4 20-10197
5 04-10002
6
02-4436·29
7 4008-01168-06
8 02-5153
9 20-8712·25
10 03·8042
• 11 31-2255-3
··12 RM·22·30
Trunk Base Bracket
Bracket, Trunk Ball Deflector
BrackeVPole Assembly
Coil Magnet
Trunk Magnet Cover Plate
F·F
Spacer #8-32
x
3.88" Long
Mach. Screw, #8-32
x
3/8"
Trunk Magnet Shaft
"E"
Ring, 1/4" Shaft
Nylon Washer
Decal
Tape - Double Sided
Associated Assemblies:
03-9317
A·20029
4008-01021-07
Maglc Trunk
Trunk and Ught w/Cable
Mach. Screw, 8·32
x
7/16" (4)
13
14
15
• Not available for individual sale. Order Decal Set 31-2255 .
•• Not shown.
5
11
