Page 515 - BallyMidway GREY Parts Catalog 16-9562-A

(S0038)
Unique Assemblies
Top View of Playfield Underside View in Raised Position
o
Item
1
2
3
4
5a
5b
6
7
8
t
Part Number Description
Chair Bracket Assembly
Bookcase Assembly
Diverter Drive Assembly
Loop Assembly (see p. 3-42eb for drawing)
Coil Magnet (3)
Bracket & Pole Piece Ass'y (3)
Lockup Loop Ass'y (see p. 3-42eb for drawing)
Kickout (Loop) Ass'y (see p. 3-42ec for drawing)
Hand Drive Assembly
Knocker Assembly
A-15258
A-14970-1
A-15040
A-14962
20-9247
A-15257
A-14964
A-15200
A-14711
A-15267
tMounted on Cabinet wall interior - see p. 2-4e for location.
(jJafPLt /MIDWAY
5-95
