Unique Assemblies - cont'd
CORVETTE (50036)
II Of [ .
--- TVUTEt "«.1_
GCl:1 10
( . j !I f p
i~~::\~C~O ~L_
t?:1
-::
,_gQ~['
====f ~~~~~;;;J ;~ilj
"
~~ I
Back Panel Assembly
A~19177
Item Part No.
Description
Item Part No.
Description
1,
A19006
Kickout Coil Assembly
12,
H·19171
Cable
2,
03·8149·9
Playfield Insert (Mini-Dome)
13,
B·12156
Lamp Assembly
3.
4808·01175·08 E-P #8 x 112" IND·PL-HWH
14,
03-8022-5
Spacer, .343" Long
4.
A·19176
Bali Gate Actuator Assembly
15.
4106-01115-12 Sh. Metal Screw, #6 x 3/4~
5,
A-17713
Three Lamp G,!. Assembly
16.
01-12569
Back. Panel Gusset Brkt.
6.
A-17712
Two Lamp G.!. Assembly
17.
4008·01113·28 Mach. Screw, 8-32 x 1·3/4"
7,
4008-01168-10 Mach.Screw, 8·32 x 5/8"
18.
23·6694·3
Rubber Ring,
5/16"
8,
03-8063·6
Bulb Sleeve, Yellow
19.
03·8247·9
Bumper Post
9.
11-1215.3
Wood Panel
20.
03·7655·4
Clamp- Cable 1/4"
10.
4408-01118-00 Nut 8-32 Tee 3/8" L.
21.
03·7655·8
Clamp- Cable 1/2"
11.
-31·1995·9
Back Panel Decal
• Not available for ind ividual. sale. Order decal set 31·1995.
