Page 503 - BallyMidway GREY Parts Catalog 16-9562-A

SEO Version

Item
1
a)
(50036)
Unique Assemblies
Top View of Playfield
Part Number
Description
Item Part Number
Description
A-19140
Engine
&
Ramp Assembly
4
A-19177
Back Panel Assembly
A-19139
Engine/Ramp Ass'y #5
a)
A-19006
Kick-Out Coil Assembly
x-isooa
Ramp Assembly
5
A-17241
Ramp Diverter Assembly
A-19135
Engine Assembly #1
6
A-19004
Race Track Assembly
A-19136
Engine Assembly #2
a)
A-19134
Gear Box Assembly
A-19137
Engine Assembly #3
b)
A-19145
Left Car Assembly
A-19138
Engine Assembly #4
c)
A-19146
Right Car Assembly
A-19l54
Exhaust Pipe Assembly
"A-17796
Ball Gate Actuator Assembly
·Used in conjunction with Ball Gate Assembly A-19001.
