Page 486 - BallyMidway GREY Parts Catalog 16-9562-A

SEO Version

(50031)
Unique Assemblies
Top View of Playfield
Underside View in Raised Position
Item Part Number
Description
Item Part Number
Description
1
A-18155
Up/Down Post Unit
6
·A-17796
Ball Gate Actuator Coil Ass'y
2
A-18222
Mini Playfield Assembly
7
A-17569
Motor Assembly
a)
A-18157
Magnet Bracket
&
Pole Piece
8
A-17633
Coin Toss Assembly
b)
20-9247
Coil Magnet
9a A-15257
Magnet Bracket
&
Pole Piece
4
A-18138
Diverter Assembly
9b 20-9247
Coil Magnet
5
A-17741
Goalie Unit Assembly
10 A-18232
Back Panel Assembly
"Used in conjunction with Ball Gate Ass'y A-17797 -1.
