Unique Assemblies - cont'd
INDIANAPOLIS 500 (50026)
Description
Turbo Motor Assembly
A-20038
Item Part Number
1 14-8021.1
2 01-13870
3 A-20047
4 02-5185-1
5 4008-01003-05
6
20-8712-25
7 H-18600-1
8
H-20206
Associated Assemblies :
@-----
9 03-9343
10 4406-01119-00
11
4700-00011-00
12 A-20065
a) 04-10047.1
b) 01-13878.1
c) A-14231
d) A-14232
e) 4004-01003-05
f)
H-20196
g) *31-2505-2
Turbo Gearmotor ,12VDC
Turbo Mtr. Mounting Bracket
Turbo Oplo PCB Assembly
M-F Spacer, 8-32
x
1.0" Lg.
Mach. Screw, 8·32
x
.31"
ME"_ Ring, 1/4" Shaft
Cable, 8"
Turbo Index Cable
Turbo Impeller
Nut
6-32
ESN
FW,
11/64
x
7116
x
16ga.
Turbo Housing Assembly
Weld Housing -Turbo
Opto Insulator
LED Assembly
Photo Transistor Assembly
Mach. Screw, 4-40
x
5/1S"
Cable
Decal
• Not for Individual sale. Order Oecal Set 31-2505.
,
,
,
.
i
~
,,,
.
,
,
,
1
~
(jJafPLt
/MIDWAY
5-65
