Page 466 - BallyMidway GREY Parts Catalog 16-9562-A

SEO Version

TWIDGHr
ZONE
(50020)
Unique Assemblies
Underside of Main Playfield
Top of Main Playfield
Item Part Number
Description
1 A-16806
Mini-Playfield Assembly
a)
A-15257
Bracket
&
Pole Piece
20-9247
Coil Magnet
b)
A-15257
Bracket
&
Pole Piece
20-9247-1
Coil Magnet
2 A-16132
Gumball Machine Ass'y
3 A-16124-1
Clock Assembly
4 A-16064
Right Diverter Ass'y
5
A-16460
Bracket
&
Nut Ass'y (2)
a)
20-9247
Coil Magnet
6 A-16361
Bridge Diverter Ass'y
7 A-16338
Shooter Diverter Ass'y
8 A-16313
Rear Diverter Ass'y
5-48
(jJaI!&j
/MIDWAY
