Plunger Assembly
A-1678D
Item Part No.
1 02-4822
2
20-8716-5
3
03-8085
4
03-8927
Description
Plunger
Roll Pin 1/8 x 7/16
Link
Extension Shaft
Plunger Assembly
A-17252
Item Part No.
1
01-11968
2
02-4878
3 03-8927
4
20-8716-5
Description
Kicker Link
Plunger
Extension Shaft
Roll Pin 1/8
x
7/16
Bell Armature Assembly
A-17767
Item Part No.
1
02-4943
2 03-8362
3 02-2963
4 20-8716-20
Description
Annature
Armature Extension
Bell Annature Stop
Roll Pin 1/8 x 3/8
Bell Armature Assembly
A-17986
Item
Part
Number
1
A-6306-1
2 02-4997
3 20-8716-20
Descr iption
Bell Armature
Sub-Ass'y
Armature Extension
Roll Pin
1/8
x
3/8
Plunger
&
Rod Assembly
A-18156
Item
Part
Number
1
02-5017
2 02-5016
3 20-8716-5
Descr iption
Plunger - Up/Oown Post
Rod - Up/Oown
Post
Roll Pin,
3/16
x
7/16
