Flipper Assemblies - cont'd
Upper Right Flipper Assembly
A-15205-R-3
(Same as A-1S20S-R-2 except lor the following Item):
Imm.
part Number
12 FL-11722
DeSCription
Ripper Coil, Green
Upper Right Flipper Assembly
A-15849-R
(Same as A-1S205-R-2 except lor the following items):
nem
Part Number
12 FL-11630
16 A-15848-R
a)
A-170S0-R
b)
A-15847
c)
02-4676
Descdplion
Ripper Coil, Red
Crank Link Assembly, Right
Flipper Crank Ass'y, Right
Flipper Unk Assembly
Link Spacer Bushing
Right Flipper Assembly - Mini Playfield
A-16976-R
(Same as A-1520S-R-2 except
for
the following ilems):
.l1em
part Number
1 A-16977-R
12 FL-11722
16 A-15848-R
a)
A-170S0-R
b)
A-1S847
c)
02-4676
Description
Flipper Base Ass'y, Right
Flipper Coil, Green
Crank Link Assembly, Right
Flipper Crank Ass'y, Right
Flipper Link Assembly
Link Spacer Bushing
Lower Right Flipper Assembly
A-15849-R-4
(Same as A-1S20S-R-2 except for the following items):
Item Part Number
12 FL-15411
16 A-15848-R
a)
A-17050-R
b)
A-15847
c)
02-4676
Description
Flipper Coil, Orange
Crank Link Assembly, Right
Flipper Crank Ass'y, Right
Flipper Link Ass'y
Link Spacer Bushing
Lower Right Flipper Assembly
A-15205-R-4
(Same as A-1S205-R-2 except for the follOwing Item):
llimI
Part Number
Description
12 FL-15411
Flipper Coil, Orange
lower Right Flipper Assembly
A-15849-R-2
(Same as A-15205-R-2 except for the following items):
l1.em
part Number
Description
16 A-15848-R
a)
A-17050-R
b)
A-15B47
c)
02-4676
Crank link Assembly, Right
Ripper Crank Ass'y, Right
Ripper Link Assembly
Link Spacer Bushing
Item
1
16
a)
b)
c)
Lower Right Flipper Assembly
A-19223-R
(Same as A-15205-R-2 except for the following items):
Part Number
A-19262
A-15848-R
A-17050-R
A-15847
02-4676
Description
Flipper Bracket Assembly
Crank Link Assembly, Right
Flipper Crank Ass'y, Right
Flipper Link Ass'y
Link Spacer Bushing
