Drop Target Assemblies - cont'd
,,
,,,
,
,
,
,
,
,
,
,,
,
I
I
I
"
,
,//
, -
_ /
---
4·Bank Drop
Target Assembly
A-18783
Item Part Number
1
A-18781
2 A-11397
3 4408-01119-00
4 AE-25-1000
5 03-7066-4
6 A-19651
7 01-9548
8 03-8334-4
9 4004-01005-04
10 A-19552
11 20-8712-25
12 4700-00072-00
13 10-392
14 10-364
15 23·6626
16 A-19666
17 4700-00016-00
18 20-8712-18
Description
Bracket & Post Assembly
Stop Bracket Assembly
Nut #8 ESN Clinch
Coil Assembly
Coil Tubing, 2.093" Long
Reset Plate Assembly
Bracket Coil Mounting
4-Bank Target Stop
Mach. Screw, #4-40 x .25
Target Cap Assembly
Retaining Clip
Flatwasher #12
Compression Spring
Extension Spring
Rubber Grommet
4-Drop Target Opto PCB Assy.
Flatwasher #8
Retaining Clip
5-10b
