Page 395 - BallyMidway GREY Parts Catalog 16-9562-A

Ball Eject Assemblies - cont'd
Ball Eject Assembly
B-9361-R-5
Associated Parts:
Item Part No. Description Item Part No. Description
1. A-6949-R Spring Plale 11. B·9362·L·2 Coil & Bracket Assy., Left
2. A-18146 Mig. Brackel Assembly a) A-17808 Bracket & Stop Assembly
3. A-7471-R Eject Cam Assembly b) 01-8-508-S Coli Retaining Bracket
4. 02-3407-2 Solenoid Plunger c) 4006-01017-06 Mach. Screw, 6-32 x 3/8'
5. 10-320 Spring-Eject, Red d) 4406-01119-00 Nut, 6-32 ESN
6. 12-6227 Hairpin Clip e) AE-26-1200 Coil Assembly
7. 4700-00030-00 Aatwasher, 17/64 x 1/2 x 15ga. f) 03-7066 Coil Tubing
8. 4700-00103-00 Aatwasher, 17/64 x 1/2 x 28ga. 12. 10-128 Spring
9. 03-8085 Armature link 13. 03-9101·18 Eject Shield, Violet
10. 20-8716·5 Roll Pin: 1/8 x 7/16'
