Rollover Wire and Bracket Assemblies - cont'd
The ADDAMS FAMILY (50038)
Quantity
- cont'd
Part Number
Description
Per Game
5647-12693-19
A-12688
R.O_ Switch Assembly
8
a) 01-8719-1
Mounting Bracket
b) 4002-01105-06
MS 2-56 x
3/8
P-PH-S (2)
c) 5070-09054-00
Diode 1N4004, 1.0A
d) 5647-12693-19
Mini Micro Switch
(See INDIANAPOLIS 500)
A-15372
Switch Bracket Assembly
1
a) 01-8652
Mounting Bracket
b} 4002-01105-06
MS 2-56 x
3/8
P-PH-S (2)
c) 5070-09054-00
Diode 1N4004, 1.0A
d) 5647-12693-19
Mini Micro Switch
5647-12693-25
=== -~
A-14962
Loop Assembly
1
--
(See p. 3-42eb)
, , 0
A-14964
4-Switch Lockup Loop Ass'y
1
--
(See p. 3-42eb)
0
0
0
I:l
A-15200
Kickout Assembly
1
(See p. 3-42ec)
Quantity
THEATRE OF MAGIC (50039)
Part Number
Description
Per Game
5647-12693-19
A-17813
RO. Switch Assembly
9
(See INDIANAPOLIS 500)
(See INDIANAPOLIS 500)
A-17B13-1
RO. Switch Assembly
4
(See WORLD CUP)
A-18973
RO. Switch Assembly
1
(See INDIANAPOLIS 500)
5647-12693-32
A-20088
3-Switch/Bracket Assembly
1
(See INDIANAPOLIS 500)
a) 01-13889
Mounting Bracket
b) 4002-01105-06
MS 2-56 x
3/8
P-PH-S (2)
5647-12693-33
c) 5070-09054-00
Diode 1N4004, 1.0A
(See The SHADOW)
d) 5647-12693-32
Mini Micro Switch
e) 5647-12693-33
Mini Micro Switch
5647-12693-34
f) 5647-12693-34
Mini Micro Switch
(See The SHADOW)
Note: See pp. 4-25 to 4-27 for assembly drawings.
4-24d
