14 A-11727
Micro Sw
&
Brkt Ass'y
Rollover Wire and Bracket Assemblies - cont'd
Ball Trough Switch Plate Assemblies - cont'd
Note: Shown with Playfield in flipped position.
TWILIGHT ZONE (50020)
C-11615
Item Part Number
Description
1 8-11616
Mounting Plate Ass'y
2 RM-21-03
#10 Tubing
3
01-60-A
Rollover Wire Bracket
4 01-60-F
Rollover Wire Bracket
5
01-3411
Rollover Wire Bracket
6 12-6546
Rollover Wireform
7 12-6547
Rollover Wireform
8
12-6747
Rollover Wireform
9 4004-01 003-10 MS 4-40 x
5/8
P-PH-S (4)
10 4005-01 005-02 MS 5-40 x
1/8
P-PH (4)
11 5070-09054-00 Diode 1N4004 1.0A (2)
12 5647-09957-00 Micro Switch (2)
13
5825-09372-00 #6 Solder lug, Bent (2)
Related assembly mounted on Playfie!d:
(jJam;
IM/DWAY
4-19
