Ball Gate Assemblies
CREATURE FROM THE
Quantity
BLACK LAGOON (20018)
Part Number
Description
Per Game
~
A·15661
Ball Gate Assembly
1
a) 01·10786
Mounting Bracket
b) 12·7045
Wireform
~
A·15662
Ball Gate Assembly
1
a)
01-10787
Mounting Bracket
b) 12-7046
Wireform
~~
A-15663
Ball Gate Assembly
1
a)
01-10788
Mounting Bracket
b)
12-7047
Wireform
TWILIGHT ZONE (50020)
Part Number
Description
Quantity
Per Game
A-13627-2
a) 01-8240
b) 01-8600
c) 01-9654-2
d) 01-10636
e) 12-6938
f) 4002·01105-07
g) 5070-09054-00
h) 5647-12693-11
1
A-16433
a) 01-11279
b) 01-11280-L
c) 01-11280-R
d) 12-7077
Switch Gate Assembly
Nut Plate #2-56
Insulator
Mounting Bracket
Switch Cover Clip
Wire form
MS 2-56 x 7/16 P-PH-S
Diode 1N4004 1.0A
Mini-Micro Switch
Shooter Gate Assembly
Mounting Bracket
Left Shooter Gate
Right Shooter Gate
Wire Hinge Pin
