Page 326 - BallyMidway GREY Parts Catalog 16-9562-A

Item Part Number
1 12 --6842- 1
2 A-19959
3 A-20046
4 12-7268
5 A-20427
6 A-20086
7 A-17797 -1
8 A-20 102
9 12-7265
10 12 -7267
11 A-20037
12 12 -7266
13 A-19958
14 12-7210
15 A-19956
12-6466 -4 *
*Location not shown.
(50039)
Wi reform , Bal Gate and Spin Target Locations
Description
Bottom Arch Wire Fence
Crossover Wire Ramp Ass'y
Switch Gate Assembly
Wireform Ball Guide (2)
Ball Gate Assembly
Ball Gate Assembly
Ball Gate Assembly
Ball Gate Assembly
Wireform Ball Guide
Wireform Ball Guide
Switch Gate Assembly
Wireform Ball Guide
Right Wire Ramp Ass'y
Rebound Wire (2)
Spin Target Assembly
Wireform Ball Guide, 1"
