Page 307 - BallyMidway GREY Parts Catalog 16-9562-A

Bottom Arch Assemblies - cont'd
Indy500 Wor1d Shadw Corvet Addam Magic Who?
Part Number Description 50026 50031 50032 50036 50038 50039 50044
Game and Part Quantity
A-13204-Game # Bottom Arch Assembly x x x x x x x
31-1008-50031 Screened Bottom Arch 1
31-1008-50038 Screened Bottom Arch 1
31-1986.1-50032 Screened Bottom Arch 1
31-1994.1 Screened Bottom Arch 1
31-2258 Screened Bottom Arch 1
31-2302 Screened Bottom Arch 1
31-2511.2 Screened Bottom Arch 1
*12-6842 Wire Fence, Chrome 1 1 1 1
·12-6842-1 Wire Fence, Brass 1 1 1
20-9041 Tinnerman Speednut 2 2 2 2 2 2 2
20-9601 Retainer Nut #8-32 4 4 4 4 4 4 4
23-6313-1 Rubber Grommet 1 1 1 1 1 1 1
4008-01017 -10 MS 8-32 x 5/8 P-RH-S 4 4 4 4 4 4 4
4700-00011-00 FW .172 x .437 x .059 4 4 4 4 4 4 4
Related Hardware (Mounted on Playfield):
01-8419 Hanger Bracket 2
01-9211 Hanger Bracket 2 2 2 2 2 2
01-12624 Mounting Bracket 2
*See pp. 4-12a and 4-13 for Wire Fences and related hardware.
Hanger Bracket
Q
01-12624
Mounting Bracket
(Typical)
The ADAMS FAMILY (50038)
(jJam; IM/DWAY 3-50a
