CORVETTE (50036)
Ramp Assemblies
23
Note: See pp. 5-85 and 5-86 for
detailed sub-assembly drawings.
2
Track Assembly
A-19004
Item Part Number
Description
Related Parts and Assemblies:
1
03-9217
Racetrack Frame
Item Part Number
Description
2 01-13069.1
Track Bottom
22 A-19259
Christmas Tree Assembly
3 01-13272
Top Bracket
a)
03-8022-5
Spacer .343 (3)
4 03-9221
Pulley (2)
b)
4406-01128-00 Nut 6-32 Keps (3)
5
A-19141
Opto Board Assembly
c)
03-8063-4
Bulb Sleeve, Red (2)
6 A-19606
Limits Opto Board Ass'y
d)
03-8063-2
Bulb Sleeve, Green (2)
7 A-19146
Right Car Assembly
e)
03-8063-6
Bulb Sleeve, Yellow (4)
8 A-19145
Left Car Assembly
f)
4006-01113-12 MS 6-32 x
3/4
PL-HWH (3)
9 20-10116
Cord (2)
g)
01-13159.1
Christmas Tree Bracket
10 10-489
Cord Spring (2)
h)
A-18820
PC Lamp Board Ass'y
11 A-19134
Gear Box Assembly
i)
*31-1995-10
Decal. Top
12 A-19013
Bottom Bracket
n
*31-1995-4
Decal, Side
13 12-7226
Wireform
23 01-13223
Track/Christmas Tree Bracket
14 02-5087
Pulley Shaft
15 H-19608
Opto Cable
Hardware:
16 03-8063-6
Bulb Sleeve, Yellow (4)
4004-01041-04 MS 4-40 x
1/4
PH-FH (3)
17
A-12887
Bulb & Socket Assembly (4)
4006-01003-06 MS 6-32 x
3/8
P-PH-SEMS (2)
18 10-491
Loop Spring (2)
4006-01003-1 0 MS 6-32 x
5/8
P-PH-SEMS (2)
19 *31-1996-1
Top Decal
4106-01114-08 SMS #6-32 x
1/2
HH-W (8)
20 *31-1996-7
Side Decal
4700-00011-00 FW .172 x .437 x .,059 (2)
21 H-19607
G.I. Cable
03-7520-2
Ty-Rap (5) - Not shown
07 -6688-t6N Rivet (4)
03-7655-4
Harness Clip (4) - Not shown
"Not available individually.
See p. 7-10b for set number.
(jJafPLt
/MIDWAY
3-42d
