Page 25 - BallyMidway GREY Parts Catalog 16-9562-A

CORVETTE (50036) - cont'd
Backbox Circuit Board Locations
Speaker/Display Panel
Item Part Number
16
17
18
19
20
21
A-17651-50036
A-15472-1
A-16917-50036
A-14039.1
A-18532
A-12697-3
Description
WPC Security CPU Board
Fliptronic n Board
WPC Sound Board
Dot Matrix Controller Board
Motor Driver Master PC Board
Power Driver PC Board
22 5901-12784-00 Dot Matrix Display/Driver Bd
Mounted in the Cabinet (See p. 2-4d for loeations):
A-17051-1 WPC Coin Door Interface Bd
A-17316 Flipper OPIO PC Board (2)
