Page 193 - BallyMidway GREY Parts Catalog 16-9562-A

Mounted Under Bottom Arch Assembly:
10 01-13638 Ball Guide
Ramp and Trough Locations
Item Part Number Description
A A-19955 Left Plastic Ramp Ass'y
B A-19791 FrontTrough Assembly
C A-19954 Right Plastic Ramp ASs'y
D A-20048 Shooter Ramp Assembly
Mounted Under Playfield:
Item Part Number
1 A-13204-50039
2 A-20064-2
3 04-10033
4 04-10031.1
5 04-10035
6 01-13819
7 04-10034
8 04-10032
9 A-20064-1
E A-19963
F A-19825
(50039)
Ball Guide and Ramp Locations
Ball Guides
Description
Bottom Arch Assembly
Left Flipper Ball Gd Ass'y
Ball Guide Assembly
Ball Guide Assembly
Ball Guide Assembly
Ball Guide
Ball Guide Assembly
Ball Guide Assembly
Right Flipper Ball Gd Ass'y
Ball Trough Assembly
Trough Assembly
(jJafPLt /MIDWAY 3-7h
