Page 184 - BallyMidway GREY Parts Catalog 16-9562-A

SAVES THE EARTH
(50022.)
Ball Guide and Ramp Locations
Main Playfield
lIem Part Number Description
1 A-17577-1 Left Flipper Ball Guide
2 01-12166 Ramp Ball Deflector
3 A-17404 Main Ramp Assembly
4 01-11818 Ball Guide
5 01-11814 Bait Guide
6 01-11921* Left Ball Popper Ramp
7 01-11160 Ball Deflector (2 used)
8 A-17177 Ramp Assembly
9 01-12387 Ball Guide
10 01-11973* Right Ball Popper Ramp
11 A-17777 Guide Ramp Assembly
12 01-11817 Bait Guide
13 01-12329 Ball Guide
14 01-12330 Ball Guide
15 A-17402 Wheel Drop Guide ASs'y
16 A-17577-2 Right Ripper Ball Guide
*Mounted under Playfield.
Mounted under Bottom Arch:
17 01-12286
18 A-16765
19 01-12417t
20 01-12448
Bottom Arch Ball Guide
Outhole Ball Trough ASs'y
Ball Guide
Bottom Arch Ball Guide
tUsed in conjunction with Kicker Ass'y.
3-6 (jJaI!&j /MIDWAY
