Page 182 - BallyMidway GREY Parts Catalog 16-9562-A

TWIUGHT
ZONE
(S0020)
Ball Guide and Ramp Locations
Ball Guides and Deflectors
(Mounted on Main Playfield)
Item Part Number Description
1 A-16203-2 Left Flipper Ball Guide
2 A-1618S Ball Guide Assembly
3 A-16186 Ball Guide Assembly
4 01-11067 Flipper Deflector
5 A-16184 Ball Guide Assembly
6 01-11064 Lett Ball Deflector
7 01-11151 Ball Guide
8 A-16796 Ball Guide Assembly
9 01-11164 Ball Guide
10 01-11648 Ball Deflector
11 01-11166 Rear Ball Deflector
12 A-1S7a5 Ball Guide Assembly
13 01-11063 Center Ball Deflector
14 A-16794 Ball Guide Assembly
15 A-16923 Right Ball Deflector Ass'y
16 01-11581 Ball Guide
17 01-11149 Ball Guide (2 used)
18 A-16751 Ball Guide Assembly
19 01-11518 Ball Guide
20 01-11219 Shooter Ball Guide
21 A-16851 Ball Guide Assembly
22 A-16203-1 Right Flipper Ball Guide
3-4 (jJaI!&j /MIDWAY
