Page 180 - BallyMidway GREY Parts Catalog 16-9562-A

(20020)
Ball Guide and Ramp Locations
Ball Guides and Deflectors
Item Part Number Description
1 A-16585 Left Bottom Arch Guide
2 01-11378-1 Left Flipper Ball Guide
3 A-16587 Ball Guide Assembly
4 01-11360 Ball Guide
5 A-16590 Ball Guide Assembly
6 01-11384 Ball Guide
7 A-16592 Ball Guide Assembly
8 A-16586 Ball Guide Assembly
9 A-16584 Ball Guide Assembly
10 A-16589 Ball Guide Assembly
11 01-11358 Ball Guide
12 01-11356 Ball Guide
13 A-16591 Ball Guide Assembly
14 01-11716 Ball Deflector
15 A-16583 Ball Guide Assembly
16 A-1658B Ball Guide Assembly
17 01-11355 BaH Guide
18 A-16593 Ball Guide Assembly
19 A-16582 Ball Guide Assembly
20 01-11306 Ball Guide
21 01-11378-2 Right Flipper Ball Guide
22 01-11367 Right Bottom Arch Guide
Mounted under Bottom Arch (A-13204-20020):
23 01- 11687 Ball Guide Assembly
(jJaI!&j /MIDWAY
3-2
