CREATURE FROM THE BLACK LAGOON (20018)
Playfield Circuit Board Locations
Underside of Playfield
Top of Playfield
~
I
t
j
I
0fL]
I
@If----,:.,f-___j
I
I
\sf®
I
I
Item
Part Number
Description
Item Part Number
Description
1
A-15441
Chase Ught II PC Bd
11 A-15621-1
Plastic Ramp Assembly
2
A-13901-1
Opto Ramp PC Bd
a)
A-160B7-1
a-Lamp Chase PC Strip
3
A-15733
4-Lamp PC Board
b)
A-160B8-1
a-Lamp Chase PC Strip
4 A-15730
4-Lamp PC Board
c)
A-16089
a-Lamp Chase PC Strip
5 A-15734
6-Lamp PC Board
12 A-156BB
Bracket
&
Board Ass'y
6
A-15732
4-Lamp PC Board
a)
C-12709
3-Lamp PC Board
7 A-13088-2
Triac Driver PC Bd
13 A-15665
Bracket
&
Board Ass'y
8
A-15728
3-Lamp PC Board
a)
A-14305
4-Lamp PC Board
9 A-15727
3-Lamp PC Board
14 A-15667
Bracket
&
Board Ass'y
10
A-15731
4-Lamp PC Board
a)
C-12709
3-lamp PC Board
15 A-15993
Bowl Assembly
a)
A-15672
a-Lamp PC Board
(Continued on p. 1-2)
