2-2
Pinball Cabinet Assemblies - cont'd
(20020)
"
-,
(B
Item Part Number
Description
Item Part Number
Description
1 C-10843-BR Leg Assembly (4)
2 A-16970-120V Line Filter Assembly
2a 5850-13271-00 Line Cordset
3 A-16883-6
Flipper Button Ass'y (2)
4 A-17316
Flipper Opto Ass'y
5
Not used
6
(See Sect.
8)
Coin Door Assembly
7 A-9174-4
lever Guide Assembly
8 A-16055
Front Molding Assembly
9 20-9663-1
·Start· Button
10 A-16482
Flipper Opto sw, left Hand
11
A-14689
WPC Coin Door Interface
Bd
12 A-15361
Tilt Mechanism Asseambly
13 5555-12929-00 Speaker 6",
an,
25W
14 5610-13491-00 WPCTransformer. 115/230V
15 (See Sect.
8)
Cashbox Assembly
A-15487
Till Switch & Cable Ass'y
Unique Assemblies:
16
a)
17
18
a)
19
A-16650
20-9846-1
20-9663-9
A-17208-1
20-0063-13
A-16943
Sw Button & Cable Ass'y
"Launch' Button (2 used)
"Extra Ball" Button
Sw Button
&
Cable Ass'y
·Super Game" Button
5-Diode Switch PC Board
"Mounted on Cabinet floor.
(jJaI!&j
/MIDWAY
