Page 93 - Williams GREEN Parts Catalog 16-9932

SEO Version

Tilt and Level Assemblies - cont'd
Tilt Switch
&
Cable Assembly
Tilt Switch
&
Cable Assembly
A-15487
A-17195
Item Part Number
Description
Item Part Numb~r
Description
1 01-1168
Bumper Switch Bracket
1 01-1168
Bumper Switch Bracket
2 SW-1A-117
Tilt Switch
2 A-17238
Tilt Switch Assembly
3
01-96
Switch Limit Bracket
3 01-96
Switch Limit Bracket
4 01-3670-1
Switch Plate
4 01-3670-1
Switch Plate
5 4005-01 003-12
MS 5-40 x
3/4
P-PH (2)
5 4005-01 003-12 MS 5-40 x 3/4 P-PH (2)
6 4405-01117-00
Nut 5-40 Hex (2)
6
4405-01117-00
Nut 5-40 Hex (2)
7 H-15478
Cable Assembly
7 H-15478
Cable Assembly
8 5070-09054-00
Diode 1N4004 1.OA
8
Not used
Level
&
Mount Assembly
A-15802-P
O)f~®
