Page 82 - Williams GREEN Parts Catalog 16-9932

2~6
Pinball Cabinet Assemblies ~cont'd
(S0030)
5
®-----
\.
\
\.
\
\.
\
@
14
\
\
\
\
\ ®
Item Part Number
A-19514
2 A~17540
a) 5850-13271 -00
3 A-laS31-1
4 A-16883-4
5 A-17316
6 A-16773 -1
7 (See Sect. 8)
8 A-18249 -1
9 20-9663 -1
10 0-12615
11 A-17051-1
12 A-15361
Description
Leg Assembly (4)
Univ'l Power Interface Ass'y
Line Cordset
Cashbox Assembly
Flipper Button Ass'y (2)
Opto Flipper Ass'y (2)
Lever Guide Assembly
Coin Door Assembly
Interlock Switch Assembly
·Start" Button
Front Molding Assembly
Coin Door Intertace PCB
Tilt Mechanism Assembly
Item Part Number
13 5610-13953-00
14 5555-12929-00
A-17195
Description
Transformer, 115/230V
Speaker 6", 4Q, 25W
Tilt Switch Assembly
Unique Assemblies:
15 t20-9663 -:20
16 A-16113 -1
"Extra Ball" Button
Gun Handle Assembly
"Mounted on Cabinet floor.
tMounted at front of Cabinet.
