Page 78 - Williams GREEN Parts Catalog 16-9932

SEO Version

Pinball Cabinet Assemblies - cont'd
5i:i1i1~::2__ .
117&1'\
THE nEXT GEnER..iJTIDR_
(50023)
Item Part Number
1 A-16970-120V
a)
5850-13271-00
2 C-10843 -2
3 A·17445-'
4 A-16883-4
5 A-17316
6 A-16773
7 (See Sect. 8)
8 A-18249-1
9 A-16055
10 20-9663 -16
11 A-1705H
12 A-1536 1
Item Part Number
13 5555-1292 .9-00
14 5610-13491 -00
A·17195
Description
Une Filler Assembly
Line Cord set
Leg Assembly (4)
Cashbox Assembly
Flipper Button Ass'y (2)
Opto Flipper Ass'y (2)
Lever Guide Assembly
Coin Door Assembly
Interlock Switch Assembly
Front Molding Assembly
"Start" Button
Coin Door Interface PCB
Till Mechanism Assembly
Unique Assemblies:
15 t20-9663-17
16 A-14747
17 tA-14754-,
*Mounled on Cabinet floor.
tMounted at front of Cabinet.
I
@
Description
Speaker
6-.
411:,
25W
Transformer,
115/230V
Tilt
Switch Assembly
"Buy-In" Button
Gun Handle Assembly
Firing Pin
Sw/Cable
Ass'y
