Page 67 - Williams GREEN Parts Catalog 16-9932

Printed Circuit Lamp Boards Assemblies - cont'd
India Star Road Demo Flint Dirty
Part Number Description 50017 50023 50024 50028 50029 50030
Game and Part Quantity
A-19498 9-Lamp PCB Assembly 1
24-8767 Twist Socket (6) (6)
24-8805 H-Wedge Socket (3) (3)
24-8768 #555 Bulb (9) (9)
A-18560 10-Lamp PCB Assembly 1
24-8767 Twist Socket (7) (7)
24-8805 H-Wedge Socket (3) (3)
24-8768 #555 Bulb (10) (10)
A-19496 tt-Larnp PCB Assembly 1
24-8767 Twist Socket (8) (8)
24-8805 H-Wedge Socket (3) (3)
24-8768 #555 Bulb (11) (11)
A-18561 13-Lamp PCB Assembly 1
24-8767 Twist Socket (13) (13)
24-8768 #555 Bulb (13) (13)
A-19272 20-Lamp PCB Assembly 1
24-8767 Twist Socket (20) (20)
24-8768 #555 Bulb (20) (20)
A-17899 25-Lamp PCB Assembly 1
24-8767 Twist Socket (20) (20)
24-8805 H-Wedge Socket (5) (5)
24-8768 #555 Bulb (25) (25)
A-17356 26-Lamp PCB Assembly 1
24-8767 Twist Socket (9) (9)
24-8805 H-Wedge Socket (17) (17)
24-8768 #555 Bulb (23) (23)
24-8802 #906 Bulb (3) (3)
A-19207 28-Lamp PCB Assembly 1
24-8767 Twist Socket (28) (28)
24-8768 #555 Bulb (28) (28)
A-16716-2 38-Lamp Combo PCB Ass'y 1
24-8767 Twist Socket (28) (28)
24-8805 H-Wedge Socket (10) (10)
24-8768 #555 Bulb (38) (38)
Notes: 1. See pp. 1-1 thru 1-6 for Lamp Board locations.
2. Matrix tables and schematics are available in the Operation Manuals listed on p. 7-1.
Lamp Board Examples
--0:=:>- 0
-D t I/---~l
, f-
/ I'\::
{ \ \ JL1 lO {a} 01
~\ / l~'<-- -_/ I
0 --?-'
""\ . ._
B-12224 C-13337
O).f~® ELECTRONICS GAMES, INC.
