Coin Door Assemblies (Domestic) - cont'd
09·61000-1
2-Slot Coin Door With Acceptors
(Entropy International
Co., Ltd.)
Item Part Number
Description
1.
A-1.9729
Coin Door Frame Kit
2
09-52000
Coin Door/USA 2-Slot & DBV K.O.
3
27-1021
Housing f/Coin Entry
4
27·1026·3
Entry Plate 25 Cent USA
5
27·1037
Reject Button
a)
27·1038
Cover f/Reject Button
b)
27·1039
Reject Spring, Conical
c)
27·1041·11
Label, 25 Cent USA
6
27-1061
Coin Return Bezel
7
27-1062
Coin Return Flap
8
27·1016
Lock & Key Assembly
9
27·4910
Top Cover Plate
10
27·4911
Bottom Cover Plate
11
5641·12724·00
Diagnostic Switch PIS 4·Bank
or 27-1008
Diagnostic Switch PIS 3-Bank
a)
03·7601·4
Rept. Button (Red) f/Diag. Switch
or
03-7601·7
Aept. Button (Black) ffDiag. Switch
12
27-1092
Coin Door Switch E53·60B
a)
27-1075
Wireform
13
09·8803
Coin Mech. USA 25 Cent
14
4408·01117 -00
Nut 8-32 Hex
15
4008-01113·04
Screw 8·32 x 1/4 HWH
16
4008·01113·12
Screw 8-32 x 3/4 HWH
17
4008·01113·16
Screw 8-32 x 1 PL-HWH
18
27-4921
Step Bracket
19
03·7655·8
Cable Clamp
1/2"
20
27-4908
Cable, Univ. Coin Door 2-Slol
21
27-1066
Switch, Slam
O)f~®
ELECTRONICS GAMES, INC.
8·7
