Unique Assemblies - cont'd
DIRTY HARRY {50030}
Playfield Gun Assembly
A·19112
tlM1
Part Number
Description
Item Part Number
Description
A·6306-2
Bell Armature Assembly
13 AE-23-800
Coil Assembly
2 A-19610
Mounting Bracket Assembly
14 03-7067-5
Coil Tubing
3 A-19339.1
Gun Coil MIg Bracket Ass'y
15 4008-01017-04 MS 8-32 x 1/4 P-RH-S (2)
4 A-16908
Opto LED Assembly - RTV
16 01-13002.3
Adjusting Bracket
5 A-16909
Opto Photo Trans Ass'y - RTV
17 A-18582
Gun Shaft Assembly
6 4106-01013-06 SMS #6-32 x 3/8 P-PH T-25 (4)
18 4008-01041-06 MS 8-32 x 3/8 P-FLH (4)
7 A-19767.4
Gun Loading Tubing Assembly
19 H-19772.1
Cable Assembly
a
4406-01119-00 Nut 6-32 ESN (2)
20 03-7520·2
Ty-Wrap 3-7/8" (2)
9 4008-01017-06 MS 8-32 x
3/8
P-RH-S (6)
Associated Part:
10 01-8-508·T
Solenoid Bracket
11 10-135
Solenoid Spring
31-2260
Decorated Playfield Gun
12 23-6420
Rubber Grommet
(See p. 7-56)
O)f~®
ELECTRONICS GAMES, INC.
5-91
