Unique
Assemblies -
cont'd
The FLiNTSTONES (50029)
REO
BlK
11
BlU
REDIWHT
"Rock Slicer" Bracket Assembly
A-17978
Item Part Number
Description
Hem Part Number
Description
1 A-17977.1
Bracket Assembly
13
Not used
2 A-18135
Wheel Assembly
14
Not used
3 14-7999
Motor
15 4700-00009-00
PN
11/64
x
7116
x 20ga.
4 02-4483
Obi Bumper Post, Hex Base (15)
16 4700-00005-00 FW
9/64
x 7/16 x 20ga. (5)
5 A-11541
Socket & Bulb Assembly
17 4406-00019-00 Nut #6-32 ESN (8)
6 A-18566
Ramp/Switch Assembly
18 4408-01119-01 Nut #8-32 ESN/NTM (2)
7 23-6556
Bumper Sleeve, Black (3)
19 A-18942-6
Playfield Plastic Assembly
8
23-6694-5
Rubber Ring
3/4-
i.d., Black (12)
20 31-1977-24
Playfield Plastic
9 03-7655-4
Cable Clamp,
1/4-
21 A-19098
Switch Bracket Assembly
10 H-18219-3
Flasher Cable Assembly
22 H-19142
Boulder Exit Sw Cable Ass'y
11 H-18600-6
Motor Cable Assembly
23 4008-01041-06 MS 8-32 x 3/8 P-FLH
12 4008-01168-10 MS 8-32 x
5/8
PL-HH-S (2)
O)f~®
ELECTRONICS GAMES, INC.
